Autotest Results for Loopback Mode
Figure 22 shows an example of Autotest results for Loopback
mode.
GPU119.EPS
Figure 22. Result for Loopback Mode
 The overall result for the Autotest.
 The loss and length measurements for the fiber:
The result exceeds the limit.
The result is within the limit.
The selected test limit does not have a limit for the test.
D
G
E
F
A
B
C
H
