Chapter 1: Get Acquainted
The Home Screen for CertiFiber Pro Modules
17
TEST: Tap TEST to do the test shown in the test setup panel.
The percentage of the tests in the project that are completed.
The tester uses the number of available IDs to calculate this
percentage. See Figure 37 on page 116. % Tested does not show
if your project contains only a Next ID list. See “About Next ID
Sets” on page 115 for more information about the Next ID list.
The type of module attached to the tester.
This icon shows when the input and output ports on the
tester’s CertiFiber Pro module are connected to the ports on the
remote’s CertiFiber Pro module and the remote tester is turned
on.
This icon shows when the talk function is on. To use the talk
function:
1 Connect the main and remote testers together through a
duplex fiber link.
2 Connect headsets to the headset jacks on the testers
3 Press the button on one of the headset microphones or
press on the remote, then speak into the
microphone.
