CertiFiber Pro Fiber Optical Loss Test Set
Users Manual
28
GPU135.EPS
Figure 8. How to Remove and Install the Connector Adapters
Keep extra adapters in
the containers provided.
Caution
Do not touch the
photodiode lens.
Caution
Turn only the collar on the adapter.
Do not use tools to remove or install
the adapters.
Slot
Key
Key
Slot
Put the key into the slot
before you turn the collar
on the adapter.
