Chapter 3: How to Certify Fiber Cabling
Settings for Fiber Tests
49
Table 2. Settings for Fiber Tests
Setting Description
Module Select the CertiFiber Pro module you will use.
Test Type Use Smart Remote mode for tests on duplex-fiber
cabling. See page 55.
Use Loopback mode for tests on patch cords and cable
spools. See page 64.
Use Far End Source mode for tests on individual fibers.
See page 72.
Bi-Directional Off: The tester does fiber tests in only one direction.
On: The tester does fiber tests in both directions. See “Bi-
Directional Tests” on page 80.
The
Bi-Directional setting is not available for Far End
Source mode.
Fiber Type Select a fiber type that is correct for the type you will
test. To see a different group of fiber types, tap MORE,
then tap a group. To make a custom fiber type, tap
Custom in the Fiber Groups list. See the Technical
Reference Handbook.
Fiber Type
Settings
IOR: The tester uses the index of refraction to calculate
the optical length of the fiber. Each fiber type includes
the value specified by the manufacturer. To use a
different IOR, make a custom fiber type. See the
Technical Reference Handbook.
Test Limit Select the correct test limit for the job. To see a different
group of limits, tap MORE, then tap the name of a
group. To make a custom limit, tap Custom in the Limit
Groups list. See the Technical Reference Handbook.
-continued-
