Chapter 3: How to Certify Fiber Cabling
Autotest in Far End Source Mode
73
Figure 23. Equipment for Autotests in Far End Source Mode
GPU130.EPS
Main and remote Versiv units
with CertiFiber Pro modules
installed
For multimode fiber: one EF-TRC
test reference cord
One singlemode adapter
For multimode fiber: one test
reference cord. For singlemode
fiber: two test reference cords.
Fiber cleaning supplies
Video probe with USB connector
(DI-1000 shown)
AC adapters with line cords
(optional)
A
B
C
E
D
F
G
