Chapter 3: How to Certify Fiber Cabling
Autotest in Far End Source Mode
79
GPU120.EPS
Figure 25. Result for Far End Source Mode
The overall result for the Autotest.
The loss and length measurements for the fiber:
The result exceeds the limit.
The result is within the limit.
The selected test limit does not have a limit for the test.
To see the results, limit, and margins for the fiber, tap the
window.
The settings the tester used for the test.
D
G
E
F
A
B
C
H
