Fluke TiS20+ - Product Familiarization: Back Components; Back Component Identification

Thermal Imager
Product Familiarization
3
Table 2 shows the back of the Product.
Table 2. Back
Item Description Item Description

LCD touch screen (display)
E
AC Adapter/Charger Input
Terminal

Connector cover
F
Control panel

USB port
G
Hand strap anchor
D
SD memory card slot
3
4
5
6
7
1
2
