FLYGT 3202 - Page 35

FLS 10 and Thermal detectors
WS003855B
FLS + Thermal detectors
FLS
TC
Max 12 V
WH/YE
T1
Control leads
+7
T1/*OG/1
Mini
BN
T2
CAS
WH/YE
T2/*BU/2
-5
BN
T15
**T3
**T4
*SUBCAB AWG
*Screened SUBCAB
∞ Ohm Overtemperature
1200 Ohm OK
430 Ohm Leakage
FLS 10 and Thermistor
WS003876B
FLS + Thermistor
T1
Control leads
Max
RD
T1/1
Thermistor
2.5 V
RD
T2
T2/2
relay
T15
Max
FLS
BN/BU
T3/3
+7
Mini
12 V
BN/BU
T16
T4/4
CAS
-5
T=25°C (77°F)
R ≤ 100 Ohm
T=135°C (275°F) (T
REF
–5°C (23°F)) R ≤ 550 Ohm
T=145°C (293°F) (T
REF
+5°C (41°F)) R ≤ 1330 Ohm
Thermal detectors, FLS disconnected
WS003869B
Thermal detectors FLS Disconnected
FLS
TC
Max 12 V
WH/YE
T1
Control leads
+7
T1/*OG/1
Mini
BN
T2
CAS
T2/*BU/2
-5
WH/YE
T15
BN
**T3
**T4
*SUBCAB AWG
*Screened SUBCAB
MAS 711
The following sensors can be used together with MAS 711:
Installation
Flygt 3202 Installation, Operation, and Maintenance Manual 33
