Figure 28: With a cooling jacket
Figure 29: Without a cooling jacket
Fill with coolant
Use a coolant that is a mixture of 70% water and 30% monopropylene glycol. The coolant
should prevent corrosion and be nonpoisonous (generally recognized as safe by the FDA
as food additives under part 184 and 182).
NOTICE:
Clean water with an anti-corrosive is an acceptable coolant when there is no risk of
freezing.
1. Fill with coolant until it overflows through the opposite hole, as shown here.
Quantity: approximately
• 5.9 L (6.2 qt.) without cooling jacket
• 25 L (26.4 qt.) with cooling jacket, versions
3202.090/.095/.180./185/.350/.390/.660/.670
• 41 L (43.3 qt.) with cooling jacket, versions
3202.800/.810/.820/.830/.840/.850/.860/.870
Maintenance
44 Flygt 3202 Installation, Operation, and Maintenance Manual
