FLYGT 3202 - Sensor Connections to the Pump

* For screened SUBCAB T3 and T4 shall also be twisted separately.
WS003824B
Screenflex and SUBCAB with functional ground
* For screened SUBCAB T3 & T4 shall also be twisted separately
T1 and T2
White insulation hose
twisted*
Screen
GN/YE
L1
L2
L3
T1
T2
BN
BK
GY
T1 and T2
White insulation hose
twisted*
Screen
BK
BK
BK
BK
BK
BK
GN/YE
1
2
3
4
5
6
T1
T2
Figure 18: Screenflex and SUBCAB with functional ground
Sensor-connection
Connection to the pump
WS003843B
Color and marking of control leads
SUBCAB 4GX/7G and
SUBCAB
Control
Screenflex
SUBCAB AWG
Screened
T1
WH T1
OG
WH T1
T2
WH T2
BU
WH T2
T3
-
-
WH T3
T4
-
-
WH T4
Figure 19: Color and marking of control leads
WS003850B
Sensor terminal clamps
T15
T16
T1
T2
Figure 20: Sensor terminal clamps
Installation
32 Flygt 3202 Installation, Operation, and Maintenance Manual
