88 Issue/Rev. 03 (8/97)
Entry Number Entry Description Translation
Output
Length
091 Batch 5
092 Trans 5
093 Preset Completed 16
094,095,**096 Preset batch volume exceeds
the maximum permitted.
3 * 24
097,098,**099 Preset batch volume is below
the minimum required.
3 * 24
100,**101 The minimum preset for this
recipe is
2 * 24
102,103,
104,105,
106,107,
108
Warning: Premature batch
termination will result in out of
blend delivery. If you desire to
terminate anyway, press
ENTER otherwise, press
CLEAR to continue.
7 * 24
109,110 Invalid ID Number. Press
CLEAR to enter.
2 * 24
111,112,113 Recipe selected is not
available. Press CLEAR to
continue.
3 * 24
114,115,**116 The preset volume will cause
the max transaction volume to
be exceeded.
3 * 24
117,**118 Fatal: Entry is out of specified
range.
2 * 24
119 Prv Err 7
120 Load Completed 16
121 Load Terminated 16
Note: The output length of each table entry signifies the maximum number of characters allowable for that particular message even though the
default message may not take up all spaces allowed.
Note: * An entry number flagged with an asterisk (*), designates that the entry description should have a leading space in the message. This
will allow for display concatenation without running words together.
Note: ** An entry number flagged with two asterisks (**), designates that the entry description should have a trailing space in the message.
This will allow for display concatenation without running words together.
Note: Any table entry that has more than one entry number are 24 character messages each. They are concatenated together to form a
scrolling message.
