89 Issue/Rev. 03 (8/97)
Appendix II
The following table provides the entry number, description of the data entry, the code reference (if any), the
number of columns required for the data, and the bytes that the item will require when saved in local storage. The
following designations are used in the byte column of the table:
* - The entry is programmable via a program code entry and is never saved in local storage. Thus,
this entry has no effect on the size of local storage.
** - The entry is always saved.
*** - Recipe volumes are never stored in local storage. They are calculated from the product
volumes. If the corresponding product volumes are not saved, these volumes will print
as zero.
**** - Transaction volumes are never saved in local storage. They are calculated from the batch
volumes. If the corresponding batch volumes are not saved in local storage, the transaction
volumes will print as zeros.
4 ** - This entry is always saved but the number of bytes depends on the number of batches
per transaction.
Items not marked are user selectable to be saved or not saved in local storage.
DELIVERY REPORT CONFIGURABLE ENTRY TABLE
Entry Description Code Ref Columns Bytes
1 Alarm History Alarm Codes 60 **
2 Transaction Completion Time and Date 8 **
3 Transaction Number 4 **
4 Response to Prompt Message One 9 4
5 Response to Prompt Message Two 9 4
6 Response to Prompt Message Three 9 4
7 Response to Prompt Message Four 9 4
8 Response to Prompt Message Five 9 4
9 Recipe Name for the First Batch Run R_ _02 9 *
10 Recipe Name for the Second Batch Run R_ _02 9 *
11 Recipe Name for the Third Batch Run R_ _02 9 *
12 Recipe Name for the Fourth Batch Run R_ _02 9 *
13 Recipe Name for the Fifth Batch Run R_ _02 9 *
14 Recipe Name for the Sixth Batch Run R_ _02 9 *
