ELECTRICAL REQUIREMENTS
Electrical wiring must be supplied from the main
apparatus electrical system to the foam pump
base unit. Use a minimum of 8 AWG wire
because minimum electrical service is as
follows:
2001 12 VDC requires 41 amps;
2002 or 2002HP 12 VDC requires 56 amps;
2001 24 VDC requires 22 amps;
2002 or 2002HP 24 VDC requires 30 amps.
The electrical power must be supplied
directly from the battery or the battery
master disconnect switch.
Braided flat ground straps are required for
ground connections. The flat straps limit the
RFI/EMI interference encountered with radios,
computers or other sensitive electronic
equipment.
CAUTION: Always disconnect the ground
straps and control cables from the Digital
Display Control Module or other FoamPro
equipment before electric arc welding at any
point on the apparatus. Failure to do so will
result in a power surge through the unit that
could cause irreparable damage to the display.
