Note: We recommend tightening the
eyebolts to 13 lb.ft (17 Nm).
Note: The eyebolts can remain installed on
the vehicle. Make sure the eyebolts are fully
tightened each time they are used.
3. Fully open the tailgate and rear lift
glass, or open the soft top cargo access
and connect the prop rod to hold open.
5. Attach upper straps 1 and 2 to the
eyebolts. Attach lower straps 3 and 4
to the forward cargo rings.
6. Place the narrow strap loop over all the
rear headrests and tighten until snug.
Note: Do not over-tighten the strap. This
may cause damage to the headrest.
7. Place the remaining harness over the
seat so it is out of the way.
Storing the Front Doors
1. Adjust the seat backrest to the optimal
seating position. Pull the lever up, and
push the backrest rearward when
storing the two front doors. This
creates more space between the front
door sail and the upper trim. Ensure the
cargo area is clear of any other items.
See Adjusting the Seat Backrest
(page 134).
2. See Securing the Door Retention
Harness earlier in this chapter and
complete Steps 1-7.
3. Open the passenger side front door and
install the door bag See Removing
and Installing the Doors (page 339).
355
2021 Bronco (TG1) Canada/United States of America, enUSA, Edition date: 202101, First-Printing
Removable Vehicle Components
