CAUTIONS
Do not touch the glass of the bulb.
Only fit bulbs of the correct
specification. See Bulb
Specification Chart (page 67).
Note: The following instructions describe
how to remove the bulbs. Fit replacements
in the reverse order unless otherwise stated.
Headlamp
Note: Remove the covers to gain access to
the bulbs.
Direction indicatorA
Headlamp high beamB
Headlamp low beamC
Direction indicator
1. Remove the headlamp. See
Removing a Headlamp (page 60).
2. Turn the bulb holder counterclockwise
and remove it.
3. Gently press the bulb into the bulb
holder, turn it counterclockwise and
remove it.
Headlamp high beam
CAUTION
Do not touch the glass of the bulb.
1. Remove the headlamp. See
Removing a Headlamp (page 60).
61
C-MAX (CB7)
Lighting
