Ford C-MAX User Manual

2. Remove the cover.
3. Disconnect the electrical connector.
4. Release the clip and remove the bulb.
Headlamp low beam
CAUTION
Do not touch the glass of the bulb.
1. Remove the headlamp. See
Removing a Headlamp (page 60).
2. Remove the cover.
3. Turn the bulb holder counterclockwise
and remove it.
4. Remove the bulb.
Cornering lamp
1. Remove the headlamp. See
Removing a Headlamp (page 60).
2. Remove the cover.
3. Disconnect the electrical connector.
4. Release the clip and remove the bulb.
Side lamp
1. Remove the headlamp. See
Removing a Headlamp (page 60).
2. Remove the cover.
3. Remove the bulb holder.
4. Remove the bulb.
62
C-MAX (CB7)
Lighting
