Introduction
The FortiGate Voice unit integrates FortiGate UTM functionality with VoIP phone PBX
functionality. A small office or an enterprise branch office can use a FortiGate Voice unit to
provide routing, Ethernet switching, Internet connectivity, UTM security, VoIP gateway,
and VoIP PBX features for the office.
FortiGate Voice-80C PBX functionality includes:
• Four Foreign eXchange Office (FXO) interfaces for connected to up to 4 standard
public switch telephone network (PSTN) phone lines
• Flexible number dial plans
• Standard VoIP PBX feature set
• Integrated dial-back up modem and optional 3G wireless cards
•Voicemail
• Message notification
• Unified messaging
• Music on hold
• Automatic Call Distribution (ACD)
• Basic conferencing
• Statistics and logging
Figure 1: FortiGate Voice Network connections
FortiFones or
other
SIP Phones
SIP
LAN
WAN
FXO (x4)
ISP
IMS
NGN
VPN
etc
Class 5
PSTN
(LEC)
SIP Trunking
LAN
LAN
SIP
SIP
PCs with
SIP Soft Phone
POTS/ISDN
Telephone
Adapters (ATA)
a/b - wire
BRI
a/b - wire
FortiGate Voice
Service Provider
Network
