FortiGate Voice web-based manager configuration reference PBX configuration
FortiGate Voice Version 4.0 Administration Guide
01-400-112851-20100127 29
http://docs.fortinet.com/ • Feedback
PBX configuration
The following explains how to configure PBX settings for your network environment.
These settings include voicemail notification settings, configuring a VoIP provider as well
as system settings such as a voicemail access code and a maximum voicemail duration
time limit.
Configuring extensions
Extensions provide specific information for how to handle actions for that extension. You
can choose the type of extension, such as SIP Phone, IVR, or Conference.
To configure extensions, go to PBX > Extension > Extension, select Create New, enter the
information and then select OK.
General PSTN interface settings
Column Settings Select to add or remove columns. This changes what information
appears.
Name The name of the PSTN interface.
Phone Number The phone number that is associated with that PSTN interface.
Display Name The name that displays on the phone’s LCD.
Echo Cancelling If enabled, a green checkmark appears. If Echo Cancelling is
disabled, a gray X appears.
Catch Caller ID If enabled, a green checkmark appears. If Catch Caller ID is disabled,
a gray X appears.
Administrative Status Status of the PSTN interface. A red down arrow indicates that the
interface is down; a green up arrow indicates that the interface is up.
PSTN interface configuration settings
Basic Options The basic options for the interface.
Name The name of the PSTN interface.
Phone Number Enter the phone number that will be associated with that interface.
Display Name Enter the name that will display on the phone’s LCD.
Echo Cancelling Select to enable Echo Cancelling.
Caller ID Options The options for caller ID on incoming calls.
Catch Caller ID Select to enable catch caller ID.
Caller ID Protocol Select from the drop-down list a caller ID protocol, such as V23.
Caller ID Indicator Select either Ring or Polarity to indicate the caller ID.
Ring # Enter a number for the number of rings before an incoming caller
receives options to leave a message on the person’s voicemail.
Hang-up Options The options for when an incoming call is not delivered to
Hang up on Polarity
Reversal
Select to have the phone hang up on polarity reversal.
Hang up on Busy Tone Select to have the phone hang up if there is a busy tone.
Busy Tone Detection Enter a number for the number of rings it takes before detecting a
busy tone.
Busy Tone Duration Enter a number in milliseconds for the duration of the busy tone.
Busy Tone Interval Enter a number in milliseconds for the busy tone interval.
Administrative Status Select to have the interface either up or down.
