6. It goes to “Strip Size”menudirectly.Capacityautomaticallydisplays148.1GB,and
at this time, you can not input any value in capacity as there is no additional volume
available.
TheavailablevaluesofStripSizerangefrom4KBto128KB.Thestripvalueshouldbe
selected based on different applications. Some suggested choices are :
 16K-Bestforsequentialtransfer.
 64K-Goodgeneralpurposestripsize.
 128K-Bestperformanceformostdesktopsandworkstations.
Thedefaultvalueis128K.Press<Enter>.
7. Select “Create Volume” and press <Enter>.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
The following are typical values:
     RAID0-128KB
     RAID10-64KB
     RAID5-64KB
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
TryRAID0-1
RAID0(Stripe)
Select Disks
128KB
148.1 GB
N/A
Create Volume
[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select
[ HELP ]
128KB
[ CREATE VOLUME MENU ]
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
Press ENTER to create the specified volume.
TryRAID0-1
RAID0(Stripe)
Select Disks
128KB
148.1 GB
N/A
Create Volume
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
[ CREATE VOLUME MENU ]
Create Volume
[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
[ HELP ]

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
