Franke F3D3SP User Manual

10
07/2 0 15
1
718.390.599, 718.387.897,
718.390.030, 718.387.300,
718.390.792, 718.390.740
2
718.390.031, 718.390.586,
718.390.032, 7 18.390.587,
718.390.793, 7 18.390.741
3
718.390.062, 718.390.839,
718.392.147, 718.390.796
Frozen fry dispenser F3D3S/F3D3/ F3D3SP/F3D3P
en
* The dosing quantity calibration can be changed (instructions on calibrating the dosing quantity can be found in
the Service Manual).
Model Single Lane Dual Lane
Electrical connection (F3D3/F3D3S)
Voltage 230 V 120 V 230 V 120 V
Phases 1 Ph/L/N/PE 1 Ph/L/N/PE
Power 1.3 kW 1.3 kW 1.3 kW 1.3 kW
Frequency
50 & 60
Hz
60 Hz
50 & 60
Hz
60 Hz
Amperes 5.5 A 11.0 A 5.5 A 11.0 A
Operating conditions and installation require-
ments
Max. ambient temperature 33 °C 33 °C
Max. humidity 60 % 60 %
Minimum rear clearance 30mm 30mm
Minimum top clearance 100 mm 100 mm
Minimum side clearance None None
Energy consumption (24 h) (F3D3P/F3D3SP)
4.05 kWh 5.1 kWh
Energy consumption (24 h) (F3D3/F3D3S)
6.2 kWh 7.5 kWh
Cooling system
Closed system, cold wall construction
Refrigerant (F3D3P/F3D3SP)
R290 R290
Refrigerant (F3D3/F3D3S)
R404A R404A
Climate class
N N
Operating temperature
–18 °C to –23 °C –18 °C to –23 °C
French fry capacity
Up to 18kg Up to 26kg
Dispensing rate
Up to 350 baskets
per hour
Up to 700 baskets
per hour
Dispensing accuracy
Plus/minus 10% of the calibration weight
for the large dosing quantity
Load size
1
[Small] 0.75 lb. (340 g) 0.75 lb. (340 g)
[Medium] 1.0 lb. (454 g) 1.0 lb. (454 g)
[Large] 1.5 lb. (680 g) 1.5 lb. (680 g)
Load size
2
[Small] 417 g 417 g
[Medium] 500 g 500 g
[Large] 625 g 625 g
Load size
3
[Small] 280 g 280 g
[Medium] 625 g 625 g
[Large] 833 g 833 g
