Fig. 04: Pushing the appli-
ance off the pallet.
Configuration 2
Configuration 1
Frozen fry dispenser Deep fryers Bagging station
Bagging station Deep fryers Frozen fry dispenser
. REMOVING THE PALLET
- Get two people to grasp the appliance at both sides.
- Carefully push the appliance forward. Hold the pallet
in place. If necessary, carefully shift the appliance
back and forth (see Fig. 04).
Pushing the appliance forward causes 2 metal
ramps to be extended which can be used to
push the appliance off the pallet without requir-
ing a fork lift.
- Push the appliance down along the metal ramps until
the front castors touch the ground.
- Carefully push the appliance off the metal ramps
until all 4 castors are on the floor.
CAUTION
Risk of injury!
The appliance is very heavy, top heavy and can easily tip. Therefore, the pallet is designed
so the appliance can only be pushed forward off the pallet with the aid of 2 metal ramps.
- Do not unpack the appliance alone. The appliance should be unpacked by two or three people.
- Do not try to push the appliance off the pallet sideways or toward the rear.
. SETTING UP THE APPLIANCE
The appliance must be set up horizontally. The ventilation openings in the housing must be kept
clear. Note the minimum clearances (see "Technical data").
The setup location must be suitable for cleaning the appliance and for rolling it forward for rear
access (for maintenance).
The appliance is set up next to the frying station. The following configurations are possible:
