FRC ThrottleXcel ELA100 User Manual

ELA100 Rev0604
13
Table 1. Error Codes
Table 2. Fault Warning Codes
RPM Message
Display Display Description
F01 N/A
F02 N/A
F03 HI RPM High RPM
F04 N/A
F05 N/A
F06 Tran Temp High transmission temperature
F07 Low Batt Low battery voltage
F08 Hi Batt High battery voltage
F09 Low Oil Low engine oil pressure
F10 Eng Temp High engine coolant temperature
RPM Message
Display Display Probable Cause
E01 NO DATA >Datalink cable not connected / connected to wrong port
>Broken wire / bad connector contact on datalink cable
E02 N/A N/A
E03 NO RPM >Datalink cable not connected / connected to wrong port
>Engine not running / ignition key on
>Broken wire / bad connector contact on alternator cable
E04 N/A N/A
E05 N/A N/A
E06 N/A N/A
E07 N/A N/A
E08 TRANS T’ >Sensor cable not connected
>Broken wire / bad connector contact on sensor cable
>Defective temperature sensor
E09 ENG OIL’ >Sensor cable not connected
>Broken wire / bad connector contact on sensor cable
>Defective pressure sensor
E10 ENG T’ >Sensor cable not connected
>Broken wire / bad connector contact on sensor cable
>Defective temperature sensor

FRC ThrottleXcel ELA100 Specifications

General

Brand	FRC
Model	ThrottleXcel ELA100
Category	Measuring Instruments
Language	English
