ELA100 Rev0604

Program Code Descriptions

When a valid four digit program code has been entered, stored data or program

options will show in the displays. (Refer to Programming.)

The MENU and SILENCE buttons are used to change the data. The SILENCE

button will select the digit that is to be changed. The MENU button will change the

digit or change the option choice.

Data Display Codes 1000

1110 - Fault Warnings

This code will display the last five (5) fault warnings that have occurred. The

RPM display will show a fault code and the message display will alternate between

showing the date and time that the fault occurred. Refer to Table 2. Fault Warnings

1120 - Maximum Engine RPM

This code will display the maximum RPM that the engine has attained.

1130 - Software Revision

This code will display the current software revision code.

Parameter Settings Codes 2000

2110 - Clock

This code will allow the clock display to be changed.

2120 - Date

This code will allow the date display to be changed.

2130 - Clear Fault Warnings

This code will allow the stored fault warnings to be cleared from memory. It will

clear the history of all five (5) fault warnings. Select YES or no.

2140 - RPM Calibration

This code will allow the digits in the RPM display to be adjusted to match a

tachometer. This is for engines that do not receive RPM data over the datalink and

have the yellow RPM signal wire (pin 12 on the 12-pin connector) connected to an

RPM source.

Exit Program Code Mode

Press the SILENCE button first then the MENU button and hold them both for 3

seconds to exit the program code mode and return to normal operation.

FRC ThrottleXcel ELA100 User Manual
