FRC ThrottleXcel ELA100 - Caterpillar 70-Pin Connector Harness Connections; Interface Information; 70-Pin OEM Connector Wiring

ELA100 Rev0604
24
Caterpillar Harness Connections
Interface Information
The ECM Remote Throttle Option has to be enabled. Refer to an authorized dealer
to program this option.
3116B, 3126B, 3176B, 3406E, C7, C10, C12 Engine Interface
Engines with 70-pin OEM connector.
+12 (24)
VDC
Ignition Key
GND
+12 (24) VDC
Pump Engaged
Interlock
8-Pin Cable
(Refer to
Figure 3 )
RED
BLK
ORG
WHT
GRN
YEL
BLU
BRN
12
12
12
12
12
K999-GN
G845-PU
Input #1 PTO ON/OFF
Switch
Input #8 (Remote
Throttle PWM)
68
56
ECM
70-Pin
Vehicle
Harness
Connector
Figure 8. Caterpillar ELA105 Wiring
(Sheet 1 of 3)
