ELA100 Rev0604
8
Controls and Indicators
All controls and indicators are located on the front of the control module. (Refer
to Figure 1.) See Operation and Programming Sections for more information.
RPM Display
Shows the current engine RPM in bright red digits during normal operations. It is
used to show error codes, fault warnings, stored data, and program features.
SILENCE Button
Pressed to suppress audio alarms. Used when accessing stored data and program
features. See the Programming Section for more information.
BATTERY VOLTAGE LED Display
Shows the real time battery voltage. The LEDs will be green when the voltage is
within normal limits and red when it is not.
OK TO PUMP LED
This LED will be on when the required interlock conditions are met and the throttle
is ready to begin pump operations.
Remote Hand Throttle Control Knob
When rotated changes the engine RPM. The engine RPM will increase or decrease
proportionally to the speed and direction the control knob is rotated.
IDLE Button
When pressed immediately sets the engine RPM to idle. This button can be used
in an emergency or for normal shut down after operations.
Message Display
The message display shows the time and date during normal operations and
warning alarms as they occur. It is used when accessing stored data and program
features.
TEMPERATURE LED Display
Shows real time engine coolant temperature. The LEDs will be green when the
temperature is within normal limits and red when it is not.
OIL PRESSURE LED Display
Shows real time engine oil pressure. The LEDs will be green when the pressure is
within normal limits and red when it is not.
MENU Button
Used when accessing stored data and program features.
