Freedom 458 Series COMBI User Manual

39
Installation
AC Output 2 AC Output 1 AC Input 2 AC Input 1
Ground Bus
Neutral Bus
Cap* Off each wire separately
Inverter AC Sub Panel
To
Inverter
AC
Loads
12 VDC Battery Bank
Class T
Fuse
Freedom 458 Installation Option 2 Freedom 458 Model 10, 15, 20, 25, 30
Sin
g
le Input/ Sin
g
le Output
30 Amp Transfer Switch Power Shares with Charger. *AC Input 2 and AC Output 2 ar
e
available only on Freedom
25 D/D and 30 D/D Models.
**Always consult Local and National Electrical Codes for proper wire size prior to installation.
Freedom 458
Inverter/Char
g
er
10/3 AWG Wire**
-
+
+ -
Hot Bus
Neutral Bus
Ground Bus
30
From Shore or Optional Generator
L1 Neu. Gnd.
Main AC Panel
Hot Bus
AC Wire Colors
Hot = Black Neutral = White Ground = Green/bare
Main
