Installation Option 5 for Freedom 15 S/D and 20 S/D
Inverter Mode
Single Input/Dual Output
External AC Power
Source
•
Single 30-amp shore power source
•
30-amp breaker from panel fed by 50-amp 120-volt single
phase (3-wire) shore power source
•
30-amp breaker from panel fed by one leg of a 50-amp
120/240-volt split phase (4-wire) shore power source
•
Generator
Power for AC loads
Split between main loads and two branch circuits for the
inverter loads (AC Output 1 and AC Output 2).
Charger
Shares power with inverter loads only.
Installation Notes
1. Use a 30-amp breaker in the main panel and the main
neutral bus to supply the power to the AC Input.
2. All 15-amp outputs should use 12- or 14-gauge* wires for
the output circuit.
3. All 20-amp outputs should use 12-gauge wires.*
4. Use a GFI (GFCI) type outlet as the first outlet in the line.
Consult Local and NEC for specific GFI installation recom-
mendations. See “Step 3: Install ground fault circuit inter-
rupters” on page 23.
5. If a generator is installed in the system, use a break-before-
make AC transfer switch to switch between shore power
and generator power. Route AC output from the transfer
switch to the Main AC Panel.
*Always consult Local and NEC for proper wire size prior to
installation.
Connecting Appliances
The inverter has two AC Outputs that are protected by inter-
nal branch rated circuit breakers. These eliminate the need for
a separate sub panel. These supply two appliance and/or
outlet circuits with power directly from the inverter AC
outputs.
