Operation
58
BATTERY CHARGING
The Freedom Inverter/Charger is designed to rapidly and
optimally charge wet, gel, or Absorbed Glass Mat (AGM) cell
deep-cycle batteries. Each model is rated at the following
maximum output current:
Model Maximum Output Current
Freedom 10 50 Amps DC
Freedom 15, 15 S/D 75 Amps DC
Freedom 20, 20 S/D 100 Amps DC
Freedom 25 D/D 130 Amps DC
Freedom 30, 30 D/D 140 Amps DC
Turning the Charger On and Off
To turn the charger on
• If your unit has dual inputs, and you have installed the
unit using one of the installation options described in the
“Installation” section, connect the power to AC Input 1.
• The Freedom Inverter/Charger automatically turns on
when you connect AC power to the AC Input.
• If you are using the Remote Control Panel or the LINK
instrument, you can use it to turn the charger on.
To turn the charger off
• Press CHARGE on the front of the unit.
Note: You can only turn the charger off when AC power is
being supplied.
• If you are using the Remote Control Panel or the LINK
instrument, you can also use it to turn the charger off.
Automatic 3-Stage Battery Charging
When you connect AC power to the Freedom Inverter/
Charger input, the battery charger automatically turns on. If
you are using the Remote Control Panel or the LINK instru-
ment, use it to turn the charger on.
The battery charger proceeds through the three charging
stages automatically, resulting in an efficient, complete charge.
