RESETTING CIRCUIT BREAKERS
Your Freedom Inverter/Charger has the following supple-
mental circuit breakers:
• S/D models have output circuit breakers (OUT1 and
OUT2) to protect the output AC circuits. These can be used
for branch circuit protection.
• INVERT/CHARGE breaker protects against sustained
inverter/charger over current conditions.
Circuit Breaker Protection in Amps
Model Invert/Charge
Freedom 10 15 Amps DC
Freedom 15 20 Amps DC
Freedom 20 25 Amps DC
Freedom 25 D/D 30 Amps DC
Freedom 30 D/D 30 Amps DC
Single Input, Dual Output Circuit Breaker Protection in Amps
ledoMrebmuNtraPegrahC/trevnI1tuptuO2tuptuO
D/S5121-1251-18510202
D/S5121-2251-18025102
D/S5121-3251-18025151
D/S0221-1202-18520202
D/D5221-2202-18035102
D/D0321-3202-18035151
To reset the circuit breakers
1. Remove the fault.
2. Reset supplemental circuit breakers by pushing the button
back in.
3. Reset integral branch circuit rated breakers by moving the
appropriate breaker switch to on.
