39| USER MANUAL
Climb Rate
Clamp
Top Fast
Bottom Slow
Arm Enable
Switch
Top Arm Enable / Disarm Disable
Middle Arm Enable / Disarm Enable
Bottom Arm Disable / Disarm Enable
TYPICAL CHANNEL MAPPINGS
The following are channel mapping configurations as set in the ALTA App. These
are recommendations only. Depending on exact radio models, these may help as
an initial configuration. However, it is up to the pilot setting up ALTA for flight to
determine if these settings are appropriate.
FUTABA 14SG/8FG
FUNCTION CHANNEL NUMBER DIRECTION
Pitch 2 Normal
Roll 1 Normal
Yaw 4 Normal
Throttle 3 Reverse
Mode 5 Normal
Home Switch 6 Reverse
Arm Enable 9 Reverse
Velocity Clamp 8 Reverse
Climb Rate Clamp 7 Reverse
SPEKTRUM DX18
FUNCTION CHANNEL NUMBER DIRECTION
Pitch 3 Reverse
Roll 2 Reverse
Yaw 4 Reverse
Throttle 1 Normal
Mode 6 Reverse
Home Switch 7 Reverse
Arm Enable 8 Normal
Velocity Clamp 10 Normal
Climb Rate Clamp 11 Normal
