Freestyle 80 - Gas Piping

&IGURE #ONNECTGASSUPPLYPIPING
(EATING/NLYBOILERSHOWN
Part number 550-142-850/0716
48
FreeStyle
®
WALL MOUNT GAS-FIRED WATER BOILER — Boiler Manual
20 Gas piping
FreeStyle® boilers are shipped ready to fire
natural gas ONLY. You must install the pro-
PANEVENTURI IFTHEBOILERWILLBE CONNECTED
to propane. See page 12. Failure to comply
could result in severe personal injury, death
or substantial property damage.
Connecting gas supply piping
1. 2EMOVEJACKETDOORANDREFERTOFigure 57 to pipe gas to boiler.
a. Place a pipe wrench on the gas line inside the jacket
when tightening the gas line assembly to the boiler gas
connection (item 1).
b. Install steel pipe fittings as shown in Figure 57!LLPIPE
fittings and gas cock are supplied by the installer.
2. 5SEPIPEDOPECOMPATIBLEWITHPROPANEGASES!PPLYSPAR-
INGLYONLYTOMALETHREADSOFPIPEJOINTSSOTHATPIPEDOPE
does not block gas flow.
Failure to apply pipe dope as detailed above can
result in severe personal injury, death or substantial
property damage.
3. Connect gas supply piping to the ½” NPT gas cock (item 2).
4. Support gas piping with hangers, not by boiler or its acces-
sories.
5. 0URGEALLAIRFROMGASSUPPLYPIPING
6. "EFOREPLACINGBOILERINOPERATIONCHECKBOILERANDITSGAS
CONNECTIONFORLEAKS
a. During any pressure testing at less than 13” w.c., close
THEGASSHUTOFFVALVEANDDISCONNECTSYSTEMGASPIPING
!THIGHERTESTPRESSURESDISCONNECTBOILERANDGASVALVE
FROMGASSUPPLYPIPING
 $ONOTCHECKFORGASLEAKSWITHANOPENmAME
use bubble test. Failure to use bubble test or check
FORGASLEAKSCANCAUSESEVEREPERSONALINJURYDEATH
or substantial property damage.
DO NOT adjust or attempt to measure gas valve
OUTLETPRESSURE4HEGASVALVEISFACTORYSETFORTHE
CORRECTOUTLETPRESSURE4HISSETTINGISSUITABLEFOR
NATURAL GASANDPROPANE!TTEMPTINGTO ALTEROR
measure the gas valve outlet pressure could result
in damage to the valve, causing potential severe
personal injury, death or substantial property dam-
age.
Flexible appliance gas connectors are NOT recom-
mended.
'ASPIPESIZING
1. See page 16FORGASLINESIZINGINFORMATION
1 Boiler gas supply connection, ½” NPT male
!,,/&4(%&/,,/7).'!2%3500,)%$"94(%).34!,,%2
2 T-handle gas cock, ½” NPT
3 Nipple, ½” NPT
4 Unions, ½” NPT
5 Nipple, ½” NPT
6 Tee, ½” NPT
7 Nipple, ½” NPT x 6”, for drip leg
8 Cap, ½” NPT
5SETWOWRENCHES when tightening gas pip-
ing at boiler, using one wrench to prevent the
BOILERGASLINECONNECTIONFROMTURNING&AILURE
to support the boiler gas connection pipe to
PREVENTITFROMTURNINGCOULDDAMAGEGASLINE
components.
Union or Coupling must be used.
