Freestyle 80 - Startup Verification Checklist

Part number 550-142-850/0716
75
FreeStyle
®
WALL MOUNT GAS-FIRED WATER BOILER — Boiler Manual
29 
Adjust and test boiler controls
1. &OLLOWINSTRUCTIONSINTHISMANUALTOSETANDVERIFYOPERATION
OFTHEBOILERCONTROLS
2. &OLLOWLOWWATERCUTOFFMANUFACTURERSINSTRUCTIONS
IF
USED
Have the following been done?
❏
Boiler and heat distribution units filled with water?
❏
Water chemistry verified per page 67?
❏
Sentinel X100 corrosion inhibitor added and water tested to
be within range?
❏
!IRPURGEDFROMSYSTEM
❏
!IRPURGEDFROMGASPIPING0IPINGCHECKEDFORLEAKS
❏
Condensate trap primed?
❏
)FBOILERHASBEENCONVERTEDTO,IQUElED0ETROLEUM,0'AS
ISPROPANECONVERSIONLABELAFlXEDTOJACKET
FreeStyle® boilers are shipped ready to fire natural
GAS/.,94OlREONPROPANEYOUMUSTFOLLOWTHE
instructions in this manual to install the propane
venturi. See page 12FORFreeStyle® 80, 120 or 155.
Failure to comply could result in severe personal
injury, death or substantial property damage.
❏
Thermostat circuit wiring checked to ensure there are no
stray voltages?
❏
Followed Operating Instructions, Figure 96, page 71?
❏
Burner flame and combustion verified per page 72?
❏
FreeStyle®CONTROLOPERATIONFORSPACEHEATINGAND$(7
IFUSEDVERIlEDPERTHISMANUAL
❏
!DDITIONALFIELDINSTALLED CONTROLSTESTEDAS OUTLINED BY
CONTROLMANUFACTURERS"OILER SHOULD BE OPERATING AND
SHOULDGOOFFWHENCONTROLSARETESTED6ERIFYCONTROLSCAUSE
automatic reset lockout or manual reset lockout as desired.)
❏
!DDITIONALFIELDINSTALLEDLIMITCONTROLSSETTO SYSTEM
temperature requirements? Balancing valves and controls
adjusted to provide design temperature to system?
❏
&LOWADJUSTEDBALANCEDFOR EACHZONEOFMULTIPLEZONES
systems?
❏
4HERMOSTATHEATANTICIPATORIFAVAILABLESETPROPERLY
❏
"OILERCYCLEDWITHTHERMOSTATSANDWITH$(7AQUASTATIF
installed) — Raised to highest setting and verified boiler goes
through normal startup cycle? Lowered to lowest setting and
VERIlEDBOILERGOESOFF
❏
Natural gas input measured? (page 72)
❏
Incoming gas pressure checked by connecting manometer to
GASVALVEAHEADOFBOILER'ASPRESSUREMUSTBEATLEASTTHE
minimum values given on page 16, with boiler operating at
high fire, and no more than 13 inches (330 mm) w.c. with
BOILEROPERATINGORBOILEROFF
❏
/BSERVEDSEVERALOPERATINGCYCLESFORPROPEROPERATION
❏
Room thermostats set to desired room temperature (and
$(7AQUASTATIFINSTALLEDTODESIRED$(7STORAGETEM-
perature)?
❏
!LLINSTRUCTIONSSHIPPEDWITHTHISBOILERREVIEWEDWITHOWNER
or maintenance person?
❏
)GNITIONSYSTEMSAFETYSHUTOFFDEVICETESTED
Before leaving:
❏
Fill in )NSTALLATIONCERTIlCATE, page 128.
❏
Return instructions to envelope and give to owner.
Fill out start-up data on the In-
stallation and Service Certificate,
page 128.
