Section 3
10
Wrap the unit in heavy plastic and place packing material around all sides of the instrument in a strong
carton. Protect the front panel with extra cardboard strips. Seal the carton with strong tape.
5. Mark the shipping carton:
DELICATE ELECTRONIC INSTRUMENT. FRAGILE.
3.3 - Environmental Requirements
The Model 9002 operates as either a benchtop or rack mounted unit. When setting up the Model 9002, be sure it
has sufficient space for proper ventilation. Ambient temperature and humidity should not exceed the values given in
the specifications of Section 2.4.3.
3.4 - Line Voltage Selection
The unit can be set up to operate on 100, 120, 220 or 240 Volts AC, at 50 or 60 Hz. Units are shipped for 120 Volt
operation unless otherwise specified at the time of purchase.
The system is delivered with a power line cord appropriate to the ordered voltage configuration. If you have received
the improper line cord for your area, please contact your local FDI representative for assistance.
Caution
MAKE SURE THE REAR PANEL POWER INPUT CONNECTOR IS IN THE CORRECT POSITION AND THE
CORRECT FUSE IS INSTALLED BEFORE APPLYING AC POWER.
See Figure 3.1
Model 9002
Installation and Setup
