Section 5
26
Table 5.9 Gain in Various Numerical Bases
Let us expand our example to call for a Pre-gain of 5.15 and a Post-gain of 12.1. Using the gain formula above, the
following decimal codes are calculated:
(5.15 - 1) x 20 = 83 = Decimal code for Pre-gain
(12.1 - 1) x 20 = 222 = Decimal code for Post-gain
The conversions to binary and hex code are shown below.
5.4.2.3 - Example of a Code $06 program
This exercise is a step-by-step example of the program calculations required for setup with a Special Code $06
program.
Model 9002
Remote Control Operation
Gain Dec Hex P7....P0
Level (bytes 6 & 7)
1 0 = $00 = 00000000
1.05 1 = $01 + 00000001
1.1 2 = $02 = 00000010
1.15 3 = $03 = 00000011
1.2 4 = $04 = 00000100
1.25 5 = $05 = 00000101
.
.
13.5 250 = $FA = 11111010
13.55 251 = $FB = 11111011
13.6 252 = $FC = 11111100
13.65 253 = $FD = 11111101
13.7 254 = $FE = 11111110
13.75 255 = $FF = 11111111
PRE7 PRE6 PRE5 PRE4 PRE3 PRE2 PRE1 PRE0
0101 0011=83
10
=53
16
PO7 PO6 PO5 PO4 PO3 PO2 PO1 PO0
1 1 0 1 1 1 1 0 =222
10
=0E
16
Sample Configuration
Channel #1
Filter Configuration #4
Desired Corner Frequency 100 Hz
Filter Mode Active
Input Configuration Single
Coupling AC
Pre-gain 2.30
Post-gain 10.05
