Section 5

5.2.1 - Listen/Talk Structure

Interactions between the Model 9002 and a remote controller should follow the command structure shown below:

5.3 - Key-Push Commands

Key-push codes instruct the unit to perform as if commanded by the front panel thus allowing the remote controller

to perform all functions available under local operation. Each Key-push codes is independent and instructs the

Model 9002 to perform front panel functions, one step at at time.

Table 5.1 lists the hex codes for the front panel function keys. These keys are described in Section 4.3.

Note

Key-push codes that control a toggled function are indicated by an asterisk [*].

Care should be taken to empty these codes only when previous system status has been defined earlier in the

program lest they inadvertently switch important functions ON or OFF.

Table 5.1 Codes for Function Keys

Model 9002

Remote Control Operation

Key Code Key Code

CH1* $40 SNG* $50

CH2 DIF

FLTR $41 ACT* $51

TYPE DC

FLTR $42 AC* $52

TYPE DC

REM $43 HZ* $53

CTL KHZ

FREQ* $20 CLR $30

GAIN DSP

Talk Listen Controller sets up Model 9002 as a Listener

"" .

"" Controller sends Command data

"" .

"" Controller sets up Model 9002 as a Talker

"" .

"" Controller receives Model 9002 data
