Section 5
28
Step # Action to be Taken
4f Get ACT/BYP status code (ACT)
Desired status = Active
ACT bit = 1
4g Get SNG/DIF configuration code (DIF)
Desired Configuration = Single
DIF bit = 0
4h Get I/O coupling code (DC)
Desired coupling = AC
DC = 0
4i Get decimal Pre-gain code
Decimal gain code = (gain - 1) x 20
Desired Pre-gain code = 2.30
Decimal Pre-gain code = (2.30 - 1) x 20
Decimal Pre-gain code = 26
4j Get Pre-gain code (PRE7 - PRE0)
Convert decimal Pre-gain code to an 8 bit binary number
26 = 00011010 = PRE7(MSB) - PRE0(LSB)
4k Get decimal Post-gain code
Decimal gain code = (gain - 1) x 20
Desired Post-gain code = 10.05
Decimal Post-gain code = (10.05 - 1) x 20
Decimal Post-gain code = 181
4l Get Post-gain code (PO7 - PO0)
Convert decimal post-gain code to an 8-bit binary number
181 = 10110101 = PO7(MSB) - PO0(LSB)
Table 5.10 shows a summary of Step 4. Using the formulas for R, F, and Gain code given in the previous sections,
we can calculate the binary numbers for this configuration that are to be inserted into the format of Table 5.6.
Table 5.10 Development of Codes for the Sample Configuration
Model 9002
Remote Control Operation
Function Value Binary Table 5.6 Location
R .1 110 R2 - R0
F 999 1111100111 F9 - F0
Status Active 1 ACT
Input Single 0 DIF
Coupling AC 0 DC
Pre-gain 2.30gain⇒26code⇒ 00011010 PRE7 - PRE0
Post-gain 10.05gain⇒181code⇒ 10110101 PO7 - PO0
To Next Page
