The following program makes use of all the special codes and many of the front panel key pushes.
The Send back codes ($0C, $0D, and $0E) are included in the program to provide feedback of the correctness of
the setup. When the program is finished and the Model 9002 is in local control, verify the filter configuration system
by performing front panel key push commands.
For two additional examples of code sequences used to send and receive data from the Model 9002, refer to
Appendix C.
Code Function
$11 Start of Program
$0F Go to remote control
$06 Set filter
$00 Channel 1
$00 Filter configuration #0
$F7 Corner freq = 50.4 Hz
$39 Range 0, DC, Single, Bypass
$0A Pre-gain = 1.5
$FB Post-gain = 13.55
$0B Go to channel N, filter M
$00 Channel 1
$01 Filter configuration #1
$3C Clear display (CLR DSP) keypad push
$31 Keypad push 1
$32 Keypad push 2
$3A Keypad push ‘.’
$36 Keypad push 6
$3B Keypad push ENT
$0C Send back channel status
$0D Send back channel definition
$0E Send back clip status
$05 Abort remote
$13 End of program
