S90-010 CS (APR 08) FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL
Page 14 COMMUNICATIONS SETUP
CHANGE COMPRESSOR MODE COMMAND:
#IDMCmID Change mode to m.
M or O = off A = Autocycle R = remote
Return message - A followed by the ID, CR, LF if
successful.
CHANGE SLIDE VALVE MODE COMMAND:
#IDMVmID Change Slide Valve mode.
to m. A = auto R = remote
Return message - A followed by the ID, CR, LF if
successful.
CLEAR FAILURE COMMAND:
#IDKFID Clear Fails
Return message - A followed by the ID, CR, LF if
successful.
CLEAR ANTIRECYCLE COMMAND:
#IDKRID Clear Recycle Delay
Return message - A followed by the ID, CR, LF if
successful.
RETURN FAILURE COMMAND:
#IDF Return Discrete Failure List Command:
Returns a 24 char data string followed by ID, CR, LF.
Position Alarm Description
1 High Discharge Pressure Shutdown
2 High Discharge Pressure Alarm
3 Low Suction Pressure Shutdown
4 Low Suction Pressure Alarm
5 Low Oil Pressure Shutdown and/or
Differential Oil Pressure Shutdown
6 Low Oil Pressure Alarm
7 High Oil Temperature Shutdown
8 High Oil Temperature Alarm
9 Low Oil Temperature Shutdown
10 Low Oil Temperature Alarm
11 High Discharge Temperature Shutdown
12 High Discharge Temperature Alarm
13 Compressor Aux. Fail- Shutdown
14 Pump Aux. Fail- Shutdown
15 Oil Level Shutdown
16 Unused - 0
17 High Oil Filter Pressure Alarm
18 Unused - 0
19 Auxiliary 1 Alarm/Shutdown
20 Auxiliary 2 Alarm/Shutdown
21 Low Motor Current - Shutdown
22 Sensor Fault
23 Unused - 0
24 Unused - 0
0 = safe 1 = alarm/shutdown
