QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 CS (APR 08)
COMMUNICATIONS SETUP Page 25
READ MESSAGE SETUP EXAMPLE
Read/Write Message
Type: Peer-To-Peer
Read/Write: Read
Target Device: 500 CPU
Local/Remote: Local
Control Block: N11:0
Control Block Length: 14
Channel: 0
Target Node: 2 (002) (this is the Quantum™ Panel ID)
Local File Address: N12:0
Target File Address/Offset: N10:0
Message Length in Elements: 50
Message Time-out (seconds): 15
(Refer to the Allen-Bradley Programming Overview
Section for more information)
Write Message Setup Example
Read/Write Message
Type: Peer-To-Peer
Read/Write: Write
Target Device: 500 CPU
Local/Remote: Local
Control Block: N11:0
Control Block Length: 14
Channel: 0
Target Node: 2 (002) (this is the Quantum™ Panel ID)
Local File Address: N12:0
Target File Address/Offset: N55:3
Message Length in Elements: 1
Message Time-out (seconds): 15
Enter 20 into N12:0 to send the command to set the
compressor in remote mode.
(Refer to the Allen-Bradley Programming Overview
Section for more information)
PLC-5/30 - Suggested Setup
Channel 0 - 25-pin D-shell serial port; supports standard
EIA RS-232C and RS-423 and is RS-422A compatible.
NOTE: Channel 0 is optically-coupled (provides high
electrical noise immunity) and can be used with most
RS-422A equipment as long as:
• Termination resistors are not used
• The distance and transmission rate are reduced
to comply with RS-423 requirements
The PLC-5’s switch 2 is used to select RS-232C, RS-
422A, or RS-423. Channel 0 can be wired for RS-422.
Following is the pin connections showing how to wire the
PLC-5 channel 0 connector to the Quantum™ for RS-422
communication:
PLC-5 CH0 Quantum™ Com-2
Pin 2 (TXD.OUT+) Pin 1 (-RX)
Pin 3 (RXD.IN+) Pin 3 (-TX)
Pin 14 (TXD.OUT-) Pin 2 (+RX)
Pin 16 (RXD.IN-) Pin 4 (+TX)
Channel 0 Setup:
Port Maximum Cable
length
RS-232C 15 m (50 ft)
RS-422A 61 m (200 ft)
RS-423 61 m (200 ft)
Important guidelines:
• When channel 0 is configured for RS-422A
compatibility, do not use terminating resistors
anywhere on the link.
• When channel 0 is configured for RS-422A
(compatible) and RS-423, do not go beyond 61 m
(200 ft). This distance restriction is independent
from the transmission rate.
Channel Configuration
Channel 0 = System (Master) for half-duplex or System
(Point-To-Point) for full-duplex
Remote Mode Change: DISABLED
Mode attention Char: \0x1b
System mode char: S
User mode char: U
Baud rate: 19200 (suggested)
Stop bits: 1
Parity: None
Station address: 5 (this devices ID#)
Control line: No Handshaking
Reply Msg Wait (20ms):
ACK timeout (20ms):
DF1 retries: 3
Msg appl timeout(30 secs):2
Error detect: BCC / CRC
RTS send delay (20ms): 0
RTS off delay (20ms): 0
Polling mode: Message Based (Do Not Allow Slave to
initiate messages)
Master Message Transmit: Between Station Polls
System (Point-To-Point) additional setup:
Duplicate Detect: OFF
NAK Receive:0
DF1 ENQS:0
(Refer to the Allen-Bradley Programming Overview
Section for more information)
PLC-5 Series and Firmware that support SL C500
commands
Model Series Firmware must
be at least:
C L
5/30
D C
A M
B J
5/40
C G
A M
B J
C G
5/60
E B
