COMMUNICATIONS SETUP Page 21
RETURN Alarms & Shutdowns – Page 2 $01F2
$ Start of command sequence.
01 Compressor ID code.
F2 Failure Annunciation command Page 2.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Message Code 7
7 Date 7 as mm/dd/yy
15 Time 7 as hh:mm:ss
23 Space
24 Message Code 8
27 Date 8 as mm/dd/yy
35 Time 8 as hh:mm:ss
43 Space
44 Message Code 9
47 Date 9 as mm/dd/yy
55 Time 9 as hh:mm:ss
63 Space
64 Message Code 10
67 Date 10 as mm/dd/yy
75 Time 10 as hh:mm:ss
83 Space
84 Message Code 11
87 Date 11 as mm/dd/yy
95 Time 11 as hh:mm:ss
103 Space
104 Message Code 12
107 Date 12 as mm/dd/yy
115 Time 12 as hh:mm:ss
123 Space
124 CS (Checksum followed by Carriage return,
Line feed.)
RETURN Alarms & Shutdowns – Page 3 $01F3
$ Start of command sequence.
01 Compressor ID code.
F3 Failure Annunciation command Page 3.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A Acknowledge
2 01 Compressor ID code.
4 Message Code 13
7 Date 13 as mm/dd/yy
15 Time 13 as hh:mm:ss
23 Space
24 Message Code 14
27 Date 14 as mm/dd/yy
35 Time 14 as hh:mm:ss
43 Space
44 Message Code 15
47 Date 15 as mm/dd/yy
55 Time 15 as hh:mm:ss
63 Space
64 Message Code 16
67 Date 16 as mm/dd/yy
75 Time 16 as hh:mm:ss
83 Space
84 Message Code 17
87 Date 17 as mm/dd/yy
95 Time 17 as hh:mm:ss
103 Space
104 Message Code 18
107 Date 18 as mm/dd/yy
115 Time 18 as hh:mm:ss
123 Space
124 CS (Checksum followed by Carriage
return, Line feed.)
