FRICK
QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 CS (APR 08)
COMMUNICATIONS SETUP Page 39
ISN Address Description of Data Module Type Value Code
P32-A22 Current mode Autocycle Start
P33-A23 Current mode Autocycle Stop
P34-A24 Current mode Autocycle Start Delay Time
P35-A25 Current mode Autocycle Stop Delay Time
P36-D01 Compressor Start Output 0 = Off, 1 = On
P37-D02 Compressor Auxiliary Input 0 = Off, 1 = On
P38-D03 Oil Pump #1 Start/Run Output 0 = Off, 1 = On
P39-D04 Oil Pump #1 Auxiliary Input 0 = Off, 1 = On
P40-D05 Slide Valve Load Output 0 = Off, 1 = On
P41-D06 Slide Valve Unload Output 0 = Off, 1 = On
P42-D07 Slide Stop Increase Output 0 = Off, 1 = On
P43-D08 Slide Stop Decrease Output 0 = Off, 1 = On
P44-D09 Liquid Injection Output 0 = Off, 1 = On
P45-D10 Hi-Vi Liquid Injection Output 0 = Off, 1 = On
P46-D11 Economizer Output 0 = Off, 1 = On
P47-D12 Balance Piston Output 0 = Off, 1 = On
P48-D13 Oil Level Input 0 = Off, 1 = On
P49-D14 High Liquid Level from System Input 0 = Off, 1 = On
P50-D15 Enclosure Heater Output 0 = Off, 1 = On
P51-D16 Hot Gas Bypass Output 0 = Off, 1 = On
P52-D17 Aux. #1 Input 0 = Off, 1 = On
P53-D18 Aux. #2 Input 0 = Off, 1 = On
P54:D19 Process Mode Select Input 0 = 1
st
Mode, 1 = 2
nd
Mode
P55:D20 Capacity Control Setpoint #2 Input 0 = Mode 1, 1 = Mode 2
P80:D21 Oil Heater Output 0 = Off, 1 = On
P81:D22 Alarm Output 0 = None, 1 = Alarm
P82:D23 Shutdown Output 0 = Shutdown, 1 = None
P83:D24 Power Assist Output 0 = Off, 1 = On
P84:D25 SPARE
ISN Address Description of Data Value Code
P56-OC01 Recycle delay time in minutes
P57-OC02 Compressor Mode 0 = Manual
1 = Automatic cycling
2 = Remote Start
P58-OC03 Slide Valve Mode 0 = Manual
1 = Automatic
2 = Remote
3 = Remote Control Setpoint
P59-OC04 Compressor Running Status 0 = Off, 1 = Running, 2 = Starting
P60-OC05 Process Control Mode 0 = Suction Pressure Control Mode 1
1 = Suction Pressure Control Mode 2
2 = Temperature Control Mode 1
3 = Temperature Control Mode 2
4 = Discharge Pressure Control Mode 1
5 = Discharge Pressure Control Mode 2
6 = User Selectable Control Mode 1
7 = User Selectable Control Mode 2
P61-OC06 Capacity Control Mode 0 = Keypad
1 = Autocycle
2 = Remote
3 = Remote I/O
4 = Remote Communications
5 = Schedule
