QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 CS (APR 08)
COMMUNICATIONS SETUP Page 57
SETTINGS – CONTINUED:
Frick
®
Address
AB
Address
Modbus
Address
Read
Only
Description of Data
380 N15:123 40381 High Discharge Pressure Mode 1 Shutdown
381 N15:124 40382 High Discharge Pressure Mode 1 Alarm
382 N15:125 40383 High Discharge Pressure Mode 2 Shutdown
383 N15:126 40384 High Discharge Pressure Mode 2 Alarm
384 N15:127 40385 High Discharge Pressure Mode 1 Shutdown Delay
385 N15:128 40386 High Discharge Pressure Mode 2 Shutdown Delay
386 N15:129 40387 High Discharge Pressure Mode 1 Alarm Delay
387 N15:130 40388 High Discharge Pressure Mode 2 Alarm Delay
388 N15:131 40389 High Discharge Pressure Mode 1 Unload
389 N15:132 40390 High Discharge Pressure Mode 2 Unload
390 N15:133 40391 High Discharge Pressure Mode 1 Stop Load
391 N15:134 40392 High Discharge Pressure Mode 2 Stop Load
392 N15:135 40393 Process Temperature Mode 1 Autocycle Start
393 N15:136 40394 Process Temperature Mode 1 Autocycle Stop
394 N15:137 40395 Process Temperature Mode 1 Autocycle Start Delay
395 N15:138 40396 Process Temperature Mode 1 Autocycle Stop Delay
396 N15:139 40397 AutoCycle Minimum Slide Valve Start
397 N15:140 40398 Low Oil Pressure Shutdown Delay
398 N15:141 40399 Low Oil Pressure Alarm Delay
FREEZE DISPLAY:
Frick
®
Address
AB
Address
Modbus
Address
Read
Only
Description of Data
399 N15:142 40400 X Freeze Recycle Delay
400 N15:143 40401 X Freeze Suction Pressure
403 N15:146 40404 X Freeze Shutdown
404 N15:147 40405 X Freeze Running
405 N15:148 40406 X Freeze Suction Temperature
406 N15:149 40407 X Freeze Discharge Pressure
407 N15:150 40408 X Freeze Discharge Temperature
408 N15:151 40409 X Freeze Oil Pressure
409 N15:152 40410 X Freeze Oil Temperature
410 N15:153 40411 X Freeze Oil Filter Pressure
411 N15:154 40412 X Freeze Oil Separator Temperature
412 N15:155 40413 X Freeze Balance Piston
413 N15:156 40414 X Freeze Process Temperature
414 N15:157 40415 X Freeze Process Setpoint
415 N15:158 40416 X Freeze Process Variable
416 N15:159 40417 X Freeze Compressor Mode
417 N15:160 40418 X Freeze Process Control Mode
419 N15:162 40420 X Freeze Slide Valve Position
420 N15:163 40421 X Freeze Slide Stop Position
421 N15:164 40422 X Freeze Slide Valve Mode
422 N15:165 40423 X Freeze Slide Stop Mode
423 N15:166 40424 X Freeze Slide Valve Increase
424 N15:167 40425 X Freeze Slide Valve Decrease
425 N15:168 40426 X Freeze Slide Stop Increase
426 N15:169 40427 X Freeze Slide Stop Decrease
427 N15:170 40428 X Freeze Stop/Force Unload
428 N15:171 40429 X Freeze Oil Pump Interlock
429 N15:172 40430 X Freeze Oil Heater
430 N15:173 40431 X Freeze Capacity Control Mode
431 N15:174 40432 X Freeze Oil Pump Mode
432 N15:175 40433 X Freeze Motor Current
433 N15:176 40434 X Freeze Motor Full Load Amps %
434 N15:177 40435 X Freeze KW Monitor
