S90-010 CS (APR 08) FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL
Page 66 COMMUNICATIONS SETUP
SETTINGS – CONTINUED
Frick
®
Address
AB
Address
Modbus
Address
Read
Only
Description of Data
1231 N23:176 41232 PID 2 Hi
g
h Limit
1232 N23:177 41233 PID 2 Low Limit
1233 N23:178 41234 PID 2 Off Value
1234 N23:179 41235 X PID 5 Control
1235 N23:180 41236 X PID 5 Action - Forward/Reverse Actin
g
1236 N23:181 41237 PID 5 Set
p
oint
1237 N23:182 41238 PID 5 DeadBand
1238 N23:183 41239 PID 5 Pro
p
ortional Gain
1239 N23:184 41240 PID 5 Inte
g
ral Gain
1240 N23:185 41241 PID 5 Derivative Gain
1241 N23:186 41242 PID 5 Hi
g
h Limit
1242 N23:187 41243 PID 5 Low Limit
1243 N23:188 41244 PID 5 Off Value
1244 N23:189 41245 X PID 6 Control
1245 N23:190 41246 X PID 6 Action - Forward/Reverse Actin
g
1246 N23:191 41247 PID 6 Set
p
oint
1247 N23:192 41248 PID 6 DeadBand
1248 N23:193 41249 PID 6 Pro
p
ortional Gain
1249 N23:194 41250 PID 6 Inte
g
ral Gain
1250 N23:195 41251 PID 6 Derivative Gain
1251 N23:196 41252 PID 6 Hi
g
h Limit
1252 N23:197 41253 PID 6 Low Limit
1253 N23:198 41254 PID 6 Off Value
1254 N23:199 41255 X PID 1 while Runnin
g
selection but off O
p
eration
1255 N23:200 41256 X PID 2 while Runnin
g
selection but off O
p
eration
1256 N23:201 41257 X PID 5 while Runnin
g
selection but off O
p
eration
1257 N23:202 41258 X PID 6 while Runnin
g
selection but off O
p
eration
1258 N23:202 41259 Economizer Override value
1259 N23:203 41260 Li
q
uid Slu
g
Alarm
1260 N23:204 41261 Li
q
uid Slu
g
Shutdown
1261 N23:205 41262 Maintenance for Oil Anal
y
sis
1262 N23:206 41263 Maintenance for Chan
g
e Filters
1263 N23:207 41264 Maintenance for Clean Oil Strainers
1264 N23:208 41265 Maintenance for Clean Li
q
uid Strainers
1265 N23:209 41266 Maintenance for Chan
g
e Coalescers
1266 N23:210 41267 Maintenance for Check and Clean Suction Screen
1267 N23:211 41268 Maintenance for Vibration Anal
y
sis
1268 N23:212 41269 Maintenance for Check Cou
p
lin
g
/Ali
g
nment
1269 N23:213 41270 Maintenance for Grease Motor
1270 N23:214 41271 Maintenance for User Maintenance Set
p
oint 1
1271 N23:215 41272 Maintenance for User Maintenance Set
p
oint 2
1272 N23:216 41273 Maintenance for User Maintenance Set
p
oint 3
1273 N23:217 41274 Maintenance for User Maintenance Set
p
oint 4
1274 N23:218 41275 Maintenance for User Maintenance Set
p
oint 5
1275 N23:219 41276 Maintenance for User Maintenance Set
p
oint 6
1276 N23:220 41277 Interval for Oil Anal
y
sis
1277 N23:221 41278 Interval for Chan
g
e Filters
1278 N23:222 41279 Interval for Clean Oil Strainers
1279 N23:223 41280 Interval for Clean Li
q
uid Strainers
1280 N23:224 41281 Interval for Chan
g
e Coalescers
1281 N23:225 41282 Interval for Check and Clean Suction Screen
1282 N23:226 41283 Interval for Check Vibration Anal
y
sis
1283 N23:227 41284 Interval for Check Cou
p
lin
g
/ Ali
g
nment
1284 N23:228 41285 Interval for Grease Motor
1285 N23:229 41286 Interval for User Maintenance Set
p
oint 1
1286 N23:230 41287 Interval for User Maintenance Set
p
oint 2
1287 N23:231 41288 Interval for User Maintenance Set
p
oint 3
1288 N23:232 41289 Interval for User Maintenance Set
p
oint 4
1289 N23:233 41290 Interval for User Maintenance Set
p
oint 5
1290 N23:234 41291 Interval for User Maintenance Set
p
oint 6
1291 N23:235 41292 X Slide Valve Unload Assist Enable/Disable
1292 N23:236 41293 User Selectable Control Channel #
