84 PB
PARTS CATALOG
Main Diagram
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 80105904 BASEWOOD VPAK 24 ALL 1
2 80091250 ASSY BASEPAN VRP07 ALL 1
3 80092000 HEATER LOWER BASEPAN 07 VRP VRP07XXXXXDL (MODELS WITH BASEPAN HEAT) 1
4 80091004 ASSY INSUL CORNER REAR LF
VRP07
ALL 1
5 80091003 ASSY INSUL CORNER REAR RH
VRP07
ALL 1
6 80091002 ASSY INSUL CORNER FRONT LF
VRP07
ALL 1
7 80091001 ASSY INSUL CORNER FRONT RH
VRP07
ALL 1
8 80091009 ASSY SOUND INSUL LEFT COND
VRP07
ALL 1
9 80091008 ASSY SOUND INSUL RIGHT COND
VRP07
ALL 1
10 80091019 ASSY FRONT PANEL VRP07 ALL 1
11 60169120 SCRIPT FRIEDRICH 2010" ALL 1
12 80091027 BRACKET SHIPPING, LARGE ALL 1
13 80083289 COIL
VCS.312X2X18RC2NA20X19H.625
MODINE
ALL 1
14 80114102 SHROUD, VPAK LARGE FOR RING ALL 1
15 80083486 SHROUD INLET RING 12K VRP
INJ
ALL 1
16 80092103 FAN 401MM CW 3 ALL 1
17 80092101 MTR 1/20 2 8PCW1BLDC WL ALL 1
18 80091035 MOTOR BRACKET MOUNTING
VRP07
ALL 1
19 80092100 COMPRERSSOR
G2RO6 06.9A13.0 07.5
ASK75D43UEZ
ALL 1
20 91400402 STUD COMP MTG ALL 3
21 61028904 GROMMET COMP LOW DENSITY ALL 3
22 80091006 ASSY INSUL REAR EVAP VRP07 ALL 1
23 80091013 ASSY INSUL BLOWER MOUNT ALL 1
24 80092102 MTR 1/4 2 8PCW0BLDC PSC ALL 1
25 80091007 ASSY INSUL BLOWER FRONT
VRP07
ALL 1
26 80092109 INLET RING EVAP BLOWER PSC ALL 1
27 80091042 BOTTOM HEATER BRACKET ALL 1
28 80102600 HEATER BRACKET ALL 1
29 80091015 HEATER TERMINAL SHIELD
VRP07
ALL 1
30 80102290 HEATER VPAK‑A24 NXT 2.5KW
230V
VRP07K25XXDX 1
FIgure 901
