85 PB
PARTS CATALOG
Main Diagram
FIgure 901
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
30 80102291 HEATER VPAK‑A24 NXT 3.4KW
230V
VRP07K34XXDX 1
30 80102295 HEATER VPAK‑A24 NXT 2.5KW
265V
VRP07R25XXDX 1
30 80102296 HEATER VPAK‑A24 NXT 3.4KW
265V
VRP07R34XXDX 1
31 80008102 FILTER AIR 19.75" X 13.75" X .75"
FIBERGLASS
ALL 1
32 80091010 ASSY INSUL LEFT EVAP VRP07 ALL 1
33 80091011 ASSY INSUL RIGHT EVAP VRP07 ALL 1
34 80083202 WALL CTRL CONNECTOR ALL 1
35 80091012 ASSY INSUL TOP EVAP VRP07 ALL 1
36 80091005 ASSY INSUL PANEL INNER VRP07 ALL 1
37 80083140 FILTER 6 X 6 X 1, PLEATED, MERV
8
VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
38 80091120 SHIELD FOR ACTUATOR AND
ELECTRONICS
VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
39 80092108 MTR 6W 1RPM CCW 220 VAC
SYNC
VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
40 60935301 SWITCH ON/OFF 10‑12A VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
41 61493915 CONTROL KNOBS S/M/L VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
42 80127510 ASSY BRKT HOLDER STAT VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
43 80091100 ASSY FRESH AIR VRP07 VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
44 80083490 FAN AXIAL 120 X 38MM 230VAC‑
OA4715
VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
45 80091215 ASSY BRACKET FRESH AIR
PREPAINTED VRP07
VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
46 80083288 COIL
VES.375X2X16RC2NA19X14H.625
MODINE
VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
47 80100301 EVAP DRAINPAN, VPAK LARGE VRP07XXXSXDX (MODELS WITH FRESHAIRE) 1
48 80083479 ASSY TUBE EEV VALVE VRP07 ALL 1
49 80080610 EEV VALVE ALL 1
50 80083485 COIL STPR EEV PQ‑M1001 ALL 1
51 80083771 ASSY TUBE TO CONDENSER ALL 1
52 80083729 TUBE TO EVAP COIL ALL 1
53 80083470 ASSY REVERSING VALVE VRP07 VRP07XXXXRDX (MODELS WITHOUT REHEAT) 1
54 25018305 REVERSING VALVE, 4‑WAY
DUNAN (PART OF 80083470)
VRP07XXXXRDX (MODELS WITHOUT REHEAT) 1
55 80083454 VALVE BODY, REFRIGERANT
ACCESS .225 (PART OF 80083470)
VRP07XXXXRDX (MODELS WITHOUT REHEAT) 2
56 80112504 SWITCH HIGH PRESSURE (PART
OF 80083470)
VRP07XXXXRDX (MODELS WITHOUT REHEAT) 1
57 80083340 SWITCH LOW PRESSURE (PART
OF 80083470)
VRP07XXXXRDX (MODELS WITHOUT REHEAT) 1
