86 PB
PARTS CATALOG
Main Diagram
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
58 80083473 COIL RV SOLENOID AC230V VRP07KXXXXDX (MODELS WITH 230V) 1
58 80083474 COIL RV SOLENOID AC265V VRP07RXXXXDX (MODELS WITH 265V) 1
59 80083293 COIL REHEAT VRP07 VRP07XXXXSDX (MODELS WITH REHEAT) 1
60 80083861 INLET TUBE EVAP EH COIL VRP07XXXXSDX (MODELS WITH REHEAT) 1
61 80083862 OUTLET TUBE EVAP RH COIL VRP07XXXXSDX (MODELS WITH REHEAT) 1
62 80083835 ASSY TUBE EEV VALVE VRP07 ‑
REHEAT
VRP07XXXXSDX (MODELS WITH REHEAT) 1
63 80080610 EEV VALVE VRP07XXXXSDX (MODELS WITH REHEAT) 1
64 80083485 COIL STPR EEV PQ‑M1001 VRP07XXXXSDX (MODELS WITH REHEAT) 1
65 80083863 TUBE EVAP TO STRAINER VRP07XXXXSDX (MODELS WITH REHEAT) 1
66 80083833 ASSY TUBE TO CONDENSER
REHEAT
VRP07XXXXSDX (MODELS WITH REHEAT) 1
67 80083839 ASSY REVERSING AND REHEAT
VALVES
VRP07XXXXSDX (MODELS WITH REHEAT) 1
68 80083840 REHEAT VALVE TRV‑0944 (PART
OF 80083839)
VRP07XXXXSDX (MODELS WITH REHEAT) 1
69 25018305 REVERSING VALVE, 4‑WAY
DUNAN (PART OF 80083839)
VRP07XXXXSDX (MODELS WITH REHEAT) 1
70 80083454 VALVE BODY, REFRIGERANT
ACCESS .225 (PART OF 80083839)
VRP07XXXXRDX (MODELS WITH REHEAT) 2
71 80112504 SWITCH HIGH PRESSURE (PART
OF 80083839)
VRP07XXXXRDX (MODELS WITH REHEAT) 1
72 80083340 SWITCH LOW PRESSURE (PART
OF 80083839)
VRP07XXXXRDX (MODELS WITH REHEAT) 1
73 80083473 COIL RV SOLENOID AC230V VRP07KXXXXDX (MODELS WITH 230V) 1
73 80083474 COIL RV SOLENOID AC265V VRP07RXXXXDX (MODELS WITH 265V) 1
74 80083293 80083293 – COIL REHEAT VRP07
230V / 265V
VRP07XXXXRDX (MODELS WITH REHEAT) 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 60‑120 DAYS LEAD TIME
X IN THE USED ON MODEL NUMBER DESIGNATES ALL MODELS FOR THAT DESIGNATION
FOR EXAMPLE VRP07XXXXXDL = ALL VRP 07 MODELS WITH BASEPAN HEAT REFER TO FIGURE 101(MODEL NUMBER
IDENTIFICATION FOR ADDITIONAL DETAILS)
FIgure 901
