Froling FHG - Menu Navigation Overview; Thermal Storage System Status Display

Boiler Control System Lambdatronic S 3200
Page 38
B0600008_US v
4
4.4 Menu Overview
 See 4.5 Menu - Storage tank
 See 4.6 Menu - Boiler
 See 4.7 Menu - System
4.5 Menu - Storage tank
4.5.1 Status display of the Thermal Storage System
Storage tank
01 ... 08
Display
Description
Storage tank top
temperature 55°C
Current temperature at Thermal Storage System top sensor.
Storage tank bottom
temperature 50°C
Current temperature at Thermal Storage System bottom sensor.
Storage tank pump control 0%
Function not used! Pump control either 0% or 100% speed!
Specifies the speed of the Thermal Storage System circulator as a
percentage of maximum speed.
