MIG/MAG welding
Safety
General tasks be-
fore MIG/MAG
welding
Only where a cooling unit and water-cooled welding torch are used:
- TPS 2700 with water cooling:
Plug the water hoses of the welding torch to the correct connection sockets on the
cooling unit
- TS 4000 / 5000, TPS 3200 / 4000 / 5000 with water cooling:
Connect the water hoses of the welding torch to the correct connection sockets
on the wire-feed unit
Plug in the mains plug
Move the mains switch to the "I" position:
- all the indicators on the control panel light up briefly
- where applicable, the cooling unit starts to run
Overview MIG/MAG welding is composed of the following sections:
- MIG/MAG synergic welding
- MIG/MAG standard manual welding
- CMT welding
- Special functions and options
- Robot welding
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safe-
ty rules
WARNING! An electric shock can be fatal. If the power source is connected to the
mains electricity supply during installation, there is a high risk of very serious in-
jury and damage. Before carrying out any work on the device make sure that:
- the power source mains switch is in the "O" position
- the power source is unplugged from the mains
NOTE! Follow the safety rules and note the operating conditions in the cool-
ing unit operating instructions.
