Fronius CMT 4000 Advanced Operating Instructions & Spare Parts

187
EN
TS/TPS 4000 MV
1)
connected to public grid at 230/400 V and 50 Hz
2)
d.c. = Duty cycle
TS/TPS 5000
Mains voltage 3 x 200-240 V
3 x 380-460 V
Mains voltage tolerance +/- 10 %
Mains frequency 50 / 60 Hz
Mains fuse protection 63/35 A slow-blow
Mains connection
1)
Restrictions possible
Primary continuous current 100% d.c.
2)
15.3 - 34.4 A
Primary continuous power 10.6 - 12.4 kVA
Cos phi 0.99
Efficiency 88 - 91 %
Welding current range
MIG/MAG 3 - 400 A
Rod electrode 10 - 400 A
TIG 3 - 400 A
Welding current at
10 min / 40 °C (104 °F) 50 % d.c.
2)
400 A
60 % d.c.
2)
365 A
100% d.c.
2)
280 - 320 A
Welding voltage range according to standard characteristic
MIG/MAG 14.2 - 34.0 V
Rod electrode 20.4 - 36.0 V
TIG 10.1 - 26.0 V
Max. welding voltage 48 V
Open circuit voltage 68 - 78 V
Degree of protection IP 23
Type of cooling AF
Insulation class F
EMC emission class A
Marks of conformity CE, CSA
Safety symbol S
Dimensions l x w x h 626 x 287 x 477 mm
24.65 x 11.30 x 18.78 in.
Weight 35.2 kg
77.6 lb.
Mains voltage 3 x 400 V
Mains voltage tolerance +/- 15 %
Mains frequency 50 / 60 Hz
Mains fuse protection 35 A slow-blow
Mains connection
1)
Restrictions possible
Primary continuous current 100% d.c.
2)
18 - 29.5 A
Primary continuous power 13.1 kVA
