63
EN
“Remote” control panel
General The Remote operating panel is fitted to the Remote power source. The Remote power
source is designed for automated and robot applications and is controlled exclusively via
the LocalNet.
The Remote power source can be operated via the following system add-ons:
- Remote controls
- Robot interfaces
- Field bus systems
Remote control
panel
No. Function
(1) Error indicator
lights up if an error has occurred. The corresponding error message is displayed
on all devices connected to the LocalNet that have a digital display.
The error messages displayed are described in the section headed “Trouble-
shooting”.
(2) Robot interface indicator
lights up when the power source is switched on and a robot interface or field bus
system is connected to the LocalNet
(3) Power source ON indicator
lights up for as long as the mains cable is plugged in and the mains switch is in
the “I” position
TransPuls Synergic 4000
(3)
(2)
(1)
